Key features

• Supports all the latest Xilinx FPGA series, including Virtex UltraScale+, Virtex UltraScale, Kintex UltraScale+, Kintex UltraScale, Virtex-7, Kintex-7, Artix-7, Spartan-7, Zynq UltraScale+ MPSoC, Zynq UltraScale+ RFSoC, Zynq-7000 AP SoC
• Native support by Xilinx Vivado® and SDK tools (version 2018.1 and later, no drivers required)
• USB interface to a host PC
• Up to x8 times faster than other known JTAG emulators for Xilinx FPGA
• Includes three UART ports (optional) with RS232C interface (460kbps max) for connecting a host PC to the UART port of DUT and debugging user applications
• Ultra-compact and ultra-light design (W53xH33xD14mm, 2.1"x1.3"x0.6", 60g, 0.15lb)
• 1.1V .. 3.6V compliant target JTAG interface
• Detectors and LED indicators of target JTAG power, JTAG clock, JTAG reset and UART ports activity
• Low cost

Debug Tools

• Xilinx Vivado® tools for uploading and debugging FPGA bitstreams
• CPU debuggers of Xilinx SDK tools
• Fast JTAG uploading and debugging speed for FPGA bitstreams and embedded CPU applications
• Industry standard UART console PC applications to communicate with target UART ports

Application Features

• Ideal for high-speed uploading and debugging of FPGA and embedded CPU applications
• A "must have" field deployable debug and diagnostic tool

Technical Support and Services

• Lifetime warranty, technical support and software updates
